Wieland Shop

Articlenr. 21.304.0857.0

Europa terminal strips without wire protection, 8-pole, nominal cross section: 1.5mm², width: 8mm, rated voltage: 400V, color: white

Price

Stock on request

Quantity

pieces

Article start page

Technical data

Downloads

Accessories

Fits with

Data sheet

drill hole distance centrically	8 mm
connectable conductor cross section fine stranded without cable end sleeve	0,75mm² - 1mm²
connectable conductor cross section fine stranded with cable end sleeve	0,75mm² - 1mm²
connectable conductor cross section solid	0,75mm² - 1,5mm²
connectable conductor cross section stranded	0,75mm² - 1mm²
rated voltage	400 V
type of electrical connection 1	screw connection
model electrical connection 2	screw connection
number of poles	8
number of clamp positions per pole	2
mounting method	direct mounting
operating temperature	-40-100°C
inflammability class of insulation material acc. with UL94	V2
width	62 mm
Rastermaß	8 mm
height NS 35/7,5	15 mm
length	16 mm
end plate necessary	no
color	grey
transparent	no

ROHS conformity status	compliant/exempted
ROHS exceptions	III-6(c)
REACH-SVHC conformity status	Duty-To-Declare
REACH-SVHC substances	Lead
REACH-SVHC CAS numbers	7439-92-1

Filename	Description	Filesize	File type
EC Declaration of Conformity	-	180.26 KB	PDF
UKCA Declaration of Conformity	-	40.80 KB	PDF
approval CSA	-	2.69 MB	PDF
approval SEV	-	1.14 MB	PDF
approval UR	-	152.64 KB	PDF
approval VDE	-	732.99 KB	PDF

Filename	Description	Filesize	File type
brochure	-	1.32 MB	PDF
catalogue	-	28.67 MB	PDF

Filename	Description	Filesize	File type
Declaración REACH SVHC	-	197.73 KB	PDF
RoHS certificate	-	197.76 KB	PDF
